Ubiquiti | SKU:
USP-PDU-HD
Ubiquiti USP-PDU-HD Power Distribution Hi-Density
Regular price
$999.00
Unit price
/
Unavailable
Ubiquiti USP-PDU-HD Power Distribution Hi-Density is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Care information
Care information
Display general product information or specific product information using metafields.
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
Ubiquiti USP-PDU-HD Power Distribution Hi-Density
Regular price
$999.00
Unit price
/
Unavailable
Highlight title
Text to highlight a key feature of your product
Description
Description
Ubiquiti USP-PDU-HD Power Distribution Hi-Density
Product Details
Power distribution unit designed to support large, rack-mounted UniFi hardware deployments.
Specifications
Mechanical
Dimensions: 1485 x 55 x 56 mm (58.5 x 2.17 x 2.2")
Weight: 6.3 kg (13.9 lb)
Enclosure Material: SGCC steel
Management: Ethernet
Networking Interface: (1) 10/100 MbE RJ45 port (3) GbE RJ45 ports for network redundancy
Power Method: 100—125V AC, 30A Max. (Derated to 24A), 50/60 Hz (NEMA L5-30P)
Power Output: (24) Power control outlets: Per Bank (Bank1: port 1 to 12, Bank2: port 17 to 28): Rating output current: 12A at 125V AC (1500W) Max. output current: 15A at 125V AC (1875W) Total: Rating output current: 24A at 125V AC (3000W) Max. output current: 30A at 125V AC (3750W) (4) USB type C ports: 5VDC 2A per port, total 20W Max. power
ESD/EMP Protection: Air: ± 8kV; contact: ± 4kV
Display: 1.3" touchscreen
Buttons: (1) Factory-reset (1) Circuit breaker
Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
Ambient Operating Humidity: 10 to 90% noncondensing
NDAA Compliant: ✓
Certifications: FCC, IC
Application Requirements
Mobile Apps: UniFi iOS™ and 10.11.0 and later Android™ 10.11.0 and later
UniFi Network: Version 8.0.24 and later
Features
- (24) Remote-reset outlets
- (4) USB-C ports
- 3 m power cord with NEMA L5-30 plug
- 1.3 LCM touchscreen with automation rotation
- Compatible with 36U racks and taller
