Ubiquiti UDM-PRO Dream Machine Pro 10G Cloud Gateway

Mount material

SGCC steel

Processor

Quad-core Arm® Cortex® A57 at 1.7 GHz

On-board storage

16 GB eMMC

Networking interface

LAN:
(8) GbE RJ45 ports
(1) 10G SFP+ port

WAN:
(1) GbE RJ45 port
(1) 10G SFP+ port

IDS/IPS throughput

3.5 Gbps*
_{*Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation.}

Power method

(1)Universal AC input, 100—240V AC, 0.6A Max., 50/60 Hz

(1) USP-RPS DC input

Power supply

AC/DC, internal, 50W

Supported voltage range

100 - 240V AC

Max. power consumption

33W

LCM display

(1) 1.3" touchscreen

Button

Factory reset

Ambient operating temperature

-10 to 45° C (14 to 104° F)

Ambient operating humidity

Certifications

CE, FCC, IC

GATEWAY EXPERIENCE

Performance

Redundant WAN with failover and load balancing
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reporting

Next-generation security

Application-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall

Advanced networking

License-free SD-WAN
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and Identity VPN
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP support

LEDs

Ethernet

Link/activity
Green: 1G
Amber: 10/100M

SFP+

Link/activity
White: 10G
Green: 1G

HDD

RPS
