Ubiquiti | SKU:
POE-24-12W-G
Ubiquiti POE-24-12W-G 24V PoE Adapter
Regular price
$15.00
Unit price
/
Unavailable
Ubiquiti POE-24-12W-G 24V PoE Adapter is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Care information
Care information
Display general product information or specific product information using metafields.
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
Ubiquiti POE-24-12W-G 24V PoE Adapter
Regular price
$15.00
Unit price
/
Unavailable
Highlight title
Text to highlight a key feature of your product
Description
Description
Ubiquiti POE-24-12W-G 24V PoE Adapter
Product Details
Ubiquiti 24 V DC PoE Adapters providing a variety of features to help protect your PoE devices.
Features
- Surge and clamping protection
- Maximum surge discharge
- Peak pulse current
- AC cable with earth ground
Specifications
| Feature | Specification |
| Dimensions | 87 x 44 x 29 mm (3.4 x 1.7 x 1.1") |
| Weight | 99 g (3.5 oz) |
| Output Voltage | 24V DC @ 0.5A |
| Gigabit LAN Port | Yes |
| LAN Activity Indicator | No |
| Remote Reset / Reset Button | Yes / Yes |
| Input Rated Voltage | 100-240V AC @ 50/60Hz |
| Input Current | 0.3A @ 120V AC, 0.2A @ 240V AC |
| Inrush Current | <30A peak @ 120V AC, <60A peak @ 230V AC |
| Efficiency | 75+% |
| Output Ripple | 1% Max. |
| Switching Frequency | 50 kHz |
| Line / Load Regulation | Line: ≤ 3% / Load: ≤ 5% |
| 2-Pair Powering | Pins 4, 5 (+) and Pins 7, 8 (-) |
| 4-Pair Powering | – |
| Operating Temperature | 0 to 40° C (32 to 104° F) |
| Storage Temperature | -30 to 70°C (-22 to 158° F) |
| Operating Humidity | 35 to 95% noncondensing |
| AC Connector | IEC-320 C6 |
| Data IN / PoE Port | RJ45 shielded socket |
| Surge Protection | Difference and Common Mode |
| Clamping Protection | 11V Data, 60V Power |
| Max. Surge Discharge | 1500A (8/20 μs) Power |
| Peak Pulse Current | 36A (10/1000 μs) Data |
| Shunt Capacitance | <5 pF data |
| Response Time | <1 ns |
| Certifications | CE, FCC, IC, UL |
