TRENDnet TPE-B541 5-Port Gigabit PoE++ Powered Managed Switch with PoE Passthrough

NDAA/TAA Compliant

Product Details

TRENDnet’s 5-Port Gigabit PoE++ Powered Managed Switch with PoE Passthrough, model TPE-B541, is powered by a PoE++ switch or injector, no AC adapter is required. The compact PoE++-powered managed switch features four gigabit PoE+ ports to power devices, such as IP cameras, VoIP handsets, and wireless access points, with a 60W total PoE power budget. Reducing unnecessary switch complexity, this PoE++ passthrough managed switch is equipped with management features such as VLANs, QoS, PoE control, and monitoring.

Specifications

Standards	IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3x IEEE 802.3af IEEE 802.3at IEEE 802.3bt IEEE 802.1d IEEE 802.1p IEEE 802.1q IEEE 802.1w
Device Interface	1 x Gigabit PoE++ in port 4 x Gigabit PoE+ out port LED indicators Wall mount
Data Transfer Rate	Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) Gigabit: 2Gbps (full duplex)
Performance	Data RAM Buffer: 512KB Switching Fabric: 10Gbps MAC Address Table: 8K entries Jumbo Frame: 10KB Forwarding rate: 7.44Mpps (64-byte packet size)
Management	HTTP Web based GUI Backup/Restore Configuration Upload Firmware
Spanning Tree	IEEE 802.1D STP (Spanning Tree protocol) IEEE 802.1w RSTP (Rapid Spanning Tree protocol)
Quality of Service (QoS)	Port-based QoS 802.1p Class of Service (CoS) Bandwidth Control/Rate Limiting per port (Min. Limit: 16Kbps) Queue Scheduling: Strict Priority (SP), Weighted Fair Queueing (WFQ)
VLAN	Port-based VLAN 802.1Q Tagged VLAN Up to 32 VLAN groups, ID Range 1-4094 VLAN port isolation Voice VLAN (8 user defined OUIs)
Multicast	IGMP Snooping v1/2 Block unknown multicast source
Port Mirror	RX, TX, or Both One to one Many to one
Storm Control	Broadcast (Min. Limit: 16Kbps) Multicast (Min. Limit: 16Kbps) Loopback Detection
Special Features	PoE++ Powered Auto-Negotiation
Power	IEEE 802.3bt Type 4 (95W), IEEE 802.3bt Type 3 (60W), or IEEE 802.3at (30W), PoE input only (no external power supply) IEEE 802.3bt Type 4 PoE PD Class 8 IEEE 802.3bt Type 3 PoE PD Class 5 IEEE 802.3at Type 2 PoE PD Class 4 IEEE 802.3af Type 1 PoE PD Class 0 Max. consumption: 7.31W (no PoE)
PoE	60W PoE budget with IEEE 802.3bt Type 4 (95W) input power 40W PoE budget with IEEE 802.3bt Type 3 (60W) input power 15W PoE budget with IEEE 802.3at (30W) input power
MTBF	503,726 hours @ 25°C
Operating Temperature	0° – 40° C (32° – 104° F)
Operating Humidity	Max. 90% non-condensing
Dimensions	170 x 105 x 28mm (4.21 x 4.13 x 1.10 in.)
Weight	450g (15.9 oz.)
Certifications	CE FCC LVD
Warranty	Lifetime Warranty*

Features

1 x Gigabit PoE++ input port
4 x Gigabit PoE+ output ports
60W PoE power budget with PoE++ Type 4 (95W) input power
Easy-to-use web-based management interface
Supports RSTP, VLAN, QoS, and IGMP Snooping
Voice VLAN for VoIP applications
Bandwidth control per port
10Gbps switching capacity
Compact fanless design
Wall-mountable metal housing
NDAA / TAA compliant (U.S. and Canada only)
Lifetime Warranty*

PACKAGE CONTENTS

TPE-B541
Quick Installation Guide
