TRENDnet  |  SKU: TEG-S83

TRENDnet TEG-S83 8-Port Gigabit Desktop Switch

Regular price $20.99

TRENDnet TEG-S83 8-Port Gigabit Desktop Switch is backordered and will ship as soon as it is back in stock.


Care information

Display general product information or specific product information using metafields.

Delivery and Shipping

Add some general information about your delivery and shipping policies.

Highlight title

Text to highlight a key feature of your product

Description

TRENDnet TEG-S83 8-Port Gigabit Desktop Switch

NDAA/TAA Compliant

Product Details

The 8-Port Gigabit Desktop Switch, model TEG-S83, provides high-bandwidth performance, ease of use, and reliability. This gigabit switch boosts office network efficiency and eliminates network congestion. It features gigabit speeds and a total switching capacity of 16Gbps with full-duplex mode. Integrate this sturdy metal gigabit switch for reliable high-speed network connectivity.

Features

  • Plug and play installation
  • 8 x Gigabit ports
  • 16Gbps switching capacity
  • Sturdy metal switch
  • Fanless design
  • NDAA / TAA compliant (U.S. and Canada only)
  • Lifetime Warranty*

Specifications

Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3ab
Device Interface
  • 8 x Gigabit ports
  • LED indicators
Data Transfer Rate
  • Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
  • Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
  • Gigabit: 2000Mbps (full duplex)
Performance
  • Switching Capacity: 16Gbps
  • RAM Buffer: 192KB
  • MAC Address Table: 4K entries
  • Forwarding Rate: 11.9Mpps (64-byte packet size)
  • Jumbo Frames: 9KB
Power
  • Input: 100 – 240V AC, 50/60 Hz, 0.2A
  • Output: 5 V DC, 1A external power adapter
  • Max. Consumption: 3.2W
Fan/Acoustics
  • Fanless design
MTBF
  • 1,451,740 hours
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions (L x W x H)
  • 160 x 25 x 109mm (6.29 x 0.98 x 4.29 in.)
Weight
  • 414g (14.6 oz.)
Certifications
  • FCC
  • CE
Warranty

PACKAGE CONTENTS

  • TEG-S83
  • Quick Installation Guide
  • Power Adapter (5V DC, 1A)
