TRENDnet TEG-S3160 16-Port Unmanaged 2.5G Desktop Switch

Name: TRENDnet TEG-S3160 16-Port Unmanaged 2.5G Desktop Switch
Brand: TRENDnet
SKU: TEG-S3160
Price: 286.99 USD
Availability: InStock

$286.99

TRENDnet TEG-S3160 16-Port Unmanaged 2.5G Desktop Switch is backordered and will ship as soon as it is back in stock.

Care information

Display general product information or specific product information using metafields.

Delivery and Shipping

Add some general information about your delivery and shipping policies.

Highlight title

Text to highlight a key feature of your product

Description

TRENDnet TEG-S3160 16-Port Unmanaged 2.5G Desktop Switch

NDAA/TAA Compliant

Product Details

Expand your network’s bandwidth and reduce digital bottlenecks with TRENDnet’s Unmanaged 2.5G Switches. These 2.5G network switches come equipped with 2.5GBASE-T RJ-45 ports that provide ultra-fast speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling. Each high-speed 2.5G switch features a durable metal enclosure and can be mounted to the wall for setup flexibility. The fanless design lowers energy consumption and eliminates operating noise. The sturdy metal housing and included rackmount brackets are well-suited for wall mount or 19” 1U rack installations. TRENDnet’s reliable 2.5G switches are cost-effective solutions to increase your network’s throughput.

Specifications

Standards	IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3z IEEE 802.3ab IEEE 802.3az IEEE 802.3bz
Device Interface	16 x 2.5G RJ-45 ports (100Mbps/1Gbps/2.5Gbps) LED indicators
Data Transfer Rate	Fast Ethernet: 100Mbps (half duplex) 200 Mbps (full duplex) Gigabit: 2Gbps (full duplex) 2.5 Gigabit: 5Gbps (full duplex)
Performance	Switching Capacity: 80Gbps RAM Buffer: 1.5MB Jumbo Frames: 12KB MAC Address Table: 16K entries Forwarding Rate: 59.52Mpps (64-byte packet size)
Special Features	Wall mountable Rack mountable
Power	Input: 90 – 264V AC, 47/63 Hz Output: 12V DC, 3A Max. Consumption: 7.26W
Fan/Acoustics	Fanless design
MTBF	223,000 hours
Operating Temperature	0° – 40° C (32° – 104° F)
Operating Humidity	Max. 90% non-condensing
Dimensions (L x W x H)	286 x 128 x 27mm (11.25 x 5.02 x 1.06 in.)
Weight	982g (2.16lbs)
Certifications	FCC CE
Warranty	Lifetime Warranty*

Features

16 x 2.5G RJ-45 ports
Compatible with existing Cat5e or better cabling
Fanless design eliminates noise
Rack mountable or wall mountable for installation flexibility
80Gbps switching capacity
IEEE 802.3bz (2.5G) compliant
NDAA / TAA compliant (U.S. and Canada only)
Lifetime Warranty*

PACKAGE CONTENTS

TEG-S3160
Quick Installation Guide
Rackmount kit
Power adapter (12V DC, 3A)
