TOA VX-030DA AMQ VX-3000 Digital Amplifier Module 210W@70V
Product Details
The VX-030DA is a Digital power amplifier used for the VX-3000 systems which is compliant with the European Standard EN54 for fire alarm systems. It is a module type with 1 channel of class-D digital power amplifier, which contribute to energy-saving and light weight design. The VX-030DA also features standby mode to be set for reducing standby power consumption. It requires a dedicated control units VX-3004F, VX-3008F, VX-3016F and power supply unit VX-3000DS.
Features
- Low loss modular class-D amplifiers
- Modules to be mounted in the frame units
- Rated power at 100 V: 300 W
- Can easily be removed or replaced
- Dust filter, easy to clean
- 50/70/100 V Output without transformer resulting in light-weight units
- Fuse easily accessible from rear
Specifications
| VX-030DA | VX-015DA | VX-050DA | |
|---|---|---|---|
| Power source |
31 V DC operating range: 20 – 33 V DC |
31 V DC operating range: 20 – 33 V DC |
31 V DC operating range: 20 – 33 V DC |
| Power / current consumption |
1.3 W (standby mode), 14 W (idle), 65 W (EN 62368-1: 1/8 rated output), 375 W (rated output) |
1.3 W (standby mode), 14 W (idle), 40 W (EN 62368-1: 1/8 rated output), 190 W (rated output) |
1.3 W (standby mode), 16 W (idle), 100 W (EN 62368-1: 1/8 rated output), 590 W (rated output) |
| Frequency response |
40 Hz - 20 kHz |
40 Hz - 20 kHz |
40 Hz - 20 kHz |
| Rated output |
300 W 100 V |
150 W 100 V |
500 W 100 V |
| Inputs |
DA control link (15-pin connector) |
DA control link (15-pin connector) |
DA control link (15-pin connector) |
| Outputs |
100 V/70 V/50 V selectable |
100 V/70 V/50 V selectable |
100 V/70 V/50 V selectable |
| Number of channels |
1 |
1 |
1 |
| Dimensions |
79 x 91 x 358.2 mm (W x H x D) |
79 x 91 x 358.2 mm (W x H x D) |
79 x 91 x 358.2 mm (W x H x D) |
| Finish |
Steel plate |
Steel plate |
Steel plate |
| Weight |
1.4 kg |
1.4 kg |
1.4 kg |
