Simplified EXMICRO2i 18Gbps 4K HDMI Extender With 2-Way 12v IR
Highlight title
Text to highlight a key feature of your product
Description
Description
Product Details
The EXMICRO2i can extend an HDMI2.0b (18Gbps) high-definition audio and video signal and two-way IR up to 50 meters (164 feet) between transmitter and receiver over a single Cat5e/6/7 cable. The EXMICRO2i supports resolutions up to 4K2K@60Hz 4:4:4, up to 18Gbps, and HDCP 2.2/1.4. In addition, the EXMICRO2i extender is equipped with two-way IR, which allows for source and display control, EDID override settings, a HDMI loop output.
The EXMICRO2i extender is one of if not the most efficient HDMI extenders available today. The Current draw is typically less than 1/4 the normal current draw making this device more efficient and smaller.
Features & Benefits
- Allows HDMI 2.0b (18Gbps) Audio/Video and 2-Way IR signals (to and from display) to be transmitted over a single Cat6/5e cable
- Built in EQ technology to eliminate
clocking issues - EDID Management (copy from display at RX, copy from display at TX, 1080p 60Hz. Stereo, 4K 60Hz. Stereo)
- Transmission Range:
- 4K@60Hz up to 50m/164ft over Cat6 cable.
- 1080P@60Hz up to 50m/164ft over Cat6 cable.
- HDCP1.4 and HDCP2.2 compliant
- Power from RX or TX
- Compact design
- 3-Year Warranty
Specifications
| Technical | |
|---|---|
| HDMI Compliance | HDMI 2.0b |
| HDCP Copliance | HDCP 2.2/1.4 |
| Video Bandwidth | 18Gbps |
| Video Resolution | Up to 4K @60Hz 4:4:4 |
| Color Space | RGB / YCbCr 4:4:4, YCbCr 4:2:2/4:2:0, YUV 4:4:4 |
| Color Depth | 8,10,12-Bit |
| HDMI Audio Formats | LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, Dolby Digital Plus(DD+), DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X |
| ESD Protection | Human body model — ±8kV (air-gap discharge) & ±4kV (contact discharge) |
| Connections | |
|---|---|
| Transmitter Inputs | 1x HDMI Type A [19-pin female] 1x SERVICE [Micro USB, Update port] |
| Transmitter Outputs | 1x HDMI Type A [19-pin female] 1x IR OUT [3.5mm Stereo Mini-jack] 1x CAT OUT [RJ45, 8-pin female] |
| Receiver Inputs | 1x IR IN [3.5mm Stereo Mini-jack] 1x CAT IN [RJ45, 8-pin female] 1x SERVICE [Micro USB, Update port] |
| Receiver Outputs | 1x HDMI Type A [19-pin female] |
| Housing | Metal |
| Color | Black |
| Dimensions | 3.5" (88mm) [W] x 2.4" (61mm) [D] x 0.7" (18mm) [H] |
| Weight | Transmitter: 160g/5.6 oz., Receiver: 155g/5.5 oz. |
| Power Supply | Input: AC 100 - 240V 50/60Hz Output: DC 12V/1A |
| Power Consumption | 3.84 W |
| Operating Temperature | 32 - 104°F / 0 - 40°C |
| Storage Temperature | -4 - 140°F / -20 - 60°C |
| Relative Humidity | 20 - 90% RH (no condensation) |
Specifications subject to change.
