Pulse PA-SM21 Audio Stereo to Mono Audio Converter

Converts stereo audio signals to be used in 70v applications.

The PA-SM21 Stereo to Mono Audio Converter can convert a stereo line level audio signal to a balanced mono audio output through the 3-pin terminal connector. It can also adapt a balanced mono audio signal to an unbalanced mono audio signal using the dual RCA outputs. Small, compact, and mountable metal chassis makes it a nice and easy solution when looking to convert your audio signal.

• Converts a stereo line level signal to a balanced mono output
• RCA input or output
• Balanced screw terminal input or output
• Compact design
• 40 Hz to 20 kHz frequency response
• Converts a balanced mono input to a mono RCA output
• Easy to mount
• TAA Compliant
• Dimensions: 3.2” W x 1.5” H x 0.9” D (82mm x 38mm x 22mm)

What’s included:
(1) Stereo to audio converter
(1) 3-pin screw terminal (Phoenix connector)
(2) Mounting screws
(1) Product manual
