Onkyo M-5010 2-Channel Amplifier
Onkyo M-5010 2-Channel Amplifier is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Care information
Care information
Display general product information or specific product information using metafields.
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
Onkyo M-5010 2-Channel Amplifier
Highlight title
Text to highlight a key feature of your product
Description
Description
Onkyo M-5010 2-Channel Amplifier
Product Details
Add the M-5010 2-channel amplifier to expand your home theater’s multi-room capabilities or to enable the 11-channel surround sound feature offered on selected Onkyo A/V receivers.
Boasting our acclaimed Wide Range Amplifier Technology (WRAT) with three-stage inverted Darlington Circuitry, this two-channel power amp is perfect for handling the fast-changing dynamics of movie soundtracks while retaining enough sensitivity to deliver all the nuances of your favorite music.
Features
- Low negative feedback circuits for reduced noise, expanded frequency response, and maximum efficiency
- Highly durable amp construction built around a thick anti-resonant metal chassis for extra vibration resistance
- All-analog circuitry for an ultra-clear sound
- High-output power supply for signal purity
- Configure your setup with selectable audio, 12-volt triggers, and rear side level adjustments
- Banana plug-compatible speaker posts included for easy integration
Specifications
Amplifer |
|
| Power Output | 75 W/Ch (8 Ohms, 1 kHz, 0.08%, 2 Channels Driven, FTC) |
| THD (Total Harmonic Distortion) | 0.08% (Rated Power) |
| Damping Factor | 60 (Front, 1 kHz, 8 Ohms) |
| Input Sensitivity and Impedance | 870 mV/20 k-Ohms (Unbalanced) |
| Rated RCA Output Level and Impedance | 0.87 V/270 Ohms (Line Out) |
| Frequency Response | 10 Hz–100 kHz/+0 dB, -3 dB |
| Signal-to-Noise Ratio | 110 dB (Line, IHF-A) |
| Speaker Impedance | 4 Ohms–16 Ohms |
General |
|
| Power Supply | AC 120 V~, 60 Hz |
| Power Consumption | 160 W |
| No-Sound Power Consumption | 45 W |
| Standby Power Consumption | 0.4 W |
| Dimensions (W x H x D) | 17 1/8˝ x 5 1/2˝ x 12 1/4˝ (435 x 139 x 311 mm) |
| Weight | 17.6 lbs. (8.0 kg) |
Downloads
