Audio Source AD5012 Twelve-Channel Six Zone Digital Power Amplifier

Audio Source AD5012 Twelve-Channel Six Zone Digital Power Amplifier

Product Details

12 channels rated at 50 watts into 8 ohms

• 75 watts per channel into 4 ohms
• 100 watts x6 bridged mono at 8 ohms
• 12 channels (6 stereo zones)
• 12 independent level controls

Features

• IR Remote control
• 2 Line Bus inputs
• 2 Line Bus outputs
• Independent inputs for all 8 channels
• Master level controls for Bus 1 and 2
• Phoenix-style speaker connectors
• Optical input
• Rear mounted treble and bass controls
• High efficiency class D topologies
• Black anodized brushed aluminum faceplate
• Bridgeable outputs
• OTP Protection (over temperature protection)
• OCP Protection (over current protection)
• LED status indicator lights
• Manual, auto, or triggered on/off
• Rack mountable (Rack ears included)
• Stereo line outputs
• 2 year warranty

Specifications

• Input Sensitivity: Variable, .350mV to full output with all level controls at max
• Frequence response: 20Hz to 20Hz
• Channel Crosstalk: 60 dB
• Less than 0.2% THD into 8 ohms at rated power
• S/N Ratio: 100 dB A-weighted
