Altronix OLS120D2 1A@12V & 2A@24V 115/230VAC

Altronix OLS120D2 1A@12V & 2A@24V 115/230VAC Altronix OLS120D2 power supply/charger converts a 115VAC, 50/60Hz or 230VAC, 50/60Hz input to a 12VDC/24VDC output and a 12VDC fixed output (see specifications).This unit has a wide range of applications for access control and security system accessories that require additional power. Input Universal input 115VAC, 50/60Hz, 0.95A or 230VAC, 50/60Hz, 0.6A. Output DC1 - 12 or 24VDC @ 3A and DC2 - 12VDC @ 1A. Note: If DC2 is not used, DC1 rating is 12VDC or 24VDC rated @ 4A max. Filtered and electronically regulated output. Short circuit and thermal overload protection. Battery Charging Built-in charger for sealed lead acid or gel type batteries. Maximum charge current 0.7A. Automatic switch over to stand-by battery when AC fails. Battery leads included. (Batteries are sold separately). Supervision AC fail supervision (form "C" contacts). Low battery supervision (form "C" contacts). Visual Indicators AC input and DC output LED indicators. Features Power ON/OFF switch (interrupts mains). Electrical Temperature: Operating: 0° C to 49° C (32° F to 120° F). Storage: - 20° C to 70° C ( - 4° F to 158° F). Relative Humidity: 85% +/- 5%. BTU/Hr. (approx.): 12VDC: 25 BTU/Hr. 24VDC: 49 BTU/Hr. System AC input VA requirement: 115VAC: 109.25VA. 230VAC: 138VA.
