Altronix NETWAY16G 16PORT MANAGE POE+ MIDSPN 480W

Altronix NETWAY16G 16PORT MANAGE POE+ MIDSPN 480W Altronix NetWay16G is a 16-port networked Managed Midspan in a 1U rack enclosure. It provides PoE/PoE+ (up to 30W power per port), and passes data at 10/100/1000 Mbps at distances up to 100m. Features also include an integral battery charger for applications requiring backup and embedded LINQ™ Technology to monitor, control, and report power and diagnostics from anywhere. Input 115VAC, 60Hz, 4.5A or 230VAC, 50/60Hz, 3A. Power Unit supplies PoE output voltage (55V) and up to 30W max. full power per port. Total power: NetWay16G - 480W IEEE 802.3af and IEEE 802.3at compliant (PoE/PoE+). Short circuit protection. Ethernet: Sixteen (16) ports for cameras/edge devices over ethernet. Wire type: 4-pair CAT5e and higher. Speed: 10/100/1000 Mbps. Functions Auto detection and protection of legacy non-PoE cameras/edge devices. Visual Indicators Yellow and Green LED (by RJ45 jack): IP Link status, 10/100/1000 Base-T/active. Green LED: Port status. Red LED: Power. Battery Charging Built-in battery charger (optional rack mount battery enclosure - RE2). Automatic switchover to stand-by battery when AC fails. (Batteries are sold separately). LINQ Technology SSL (Secure Socket Layer) security encryption. User level security. Built-in IP management allows for remote camera reset and monitoring. Provides local and/or remote access to critical information via LAN/WAN Email and Windows Dashboard Alert notifications report real-time diagnostics. Event log tracks history. Temperature Operating: - 20° C to 40° C ( - 4° F to 104° F). Storage: - 20° to 70° C ( - 4° F to 158° F). Relative Humidity: 85% +/- 5%. BTU/Hr. (approx.): 245 BTU/Hr. Operating Altitude: Up to 2,000m.
